Features & Highlights :
1. Digital display for parameters, parameter settings & fault indication.
2. Digital code lock for system parameter settings
3. Inbuilt starter.
4. Probe-less dry run sensing
5. Precise water level sensing in both SUMP tank & OVER HEAD tank
to avoid wastage of water.
6. Fully automated operation.
7. Protection of pump motor from over current & under current.
8. Protection of motor against Single Phasing & reverse current phasing in three phase panels
9. Complete protection of pump motor.
10. provision for Float switch & sensors for water level detection.
11. Highly accurate reliable & user friendly panel operation.
12. Also available with RTC (Real Time Clock) as per customer requirements.
13. Manual START STOP push button to start & stop the motor in case of circuit failure in DOL & STAR DELTA Panels.
14. Anti rusting coating for enclosures of panel with IP 54 standard enclosures.
Basic working Principle of panel
To transfer water from one tank to other tank depending on water level. It can also be used to transfer water from one water source to other water source by Automatically sensing the water level through sensors which turns ON and OFF The PUMP motor at a desired level which avoids the wastage of water in AUTO MODE. This Panel can also be operated in Manual mode in which the PUMP can be turn ON and OFF directly. In Manual mode only level sensors are bypassed rest all protections are functional. Thus the panel delivers Fully automated operation with complete protection of pump and motor
Applications of Panel
I. The panel is best suited & comprises of fully automated
controlling logic for water transferring from sump tank to over
head tank in residential societies, hospitals, restaurants,
industries etc.
II. The panel can also be used in the hilly areas to full fill water
requirements
Other Variants
I. TTC panel is available in DELUXE type with controlling two pump in Alternate operation mode by keeping one pump in operation mode & other in standby mode.
II. TTC panel is also available with starting method as DOL & STAR DELTA from 7.5HP to above versions.
III. TTC panel also comprises of ECONOMY CATEGORY for the users.
